Asus ROG Strix X570-F Socket Am4 Ddr4 Aura Sync RGB 5-Way Optimization Easy DIY Gaming Motherboard
ASUS

Asus ROG Strix X570-F Socket Am4 Ddr4 Aura Sync RGB 5-Way Optimization Easy DIY Gaming Motherboard

Available:Out of Stock
    ₱13,988.00
    Delivery Options
    • Nationwide Delivery
    Payment Options
    • cash-on-delivery
    • 7eleven
    • gcredit
    • GCash
    • BillEase
    • GrabPay
    • Paymaya
    • Visa
    • Mastercard
    Warranty

    1 Year Warranty

    EasyFix Warranty

    Product Description

    Unleash gaming dominance with the Asus ROG Strix X570-F motherboard. Socket AM4, DDR4 support, and premium features define this gaming powerhouse. Elevate your rig's performance and style with unparalleled reliability.

    Product Specifications

    • Brand: ASUS
    • Series: ‎ROG STRIX X570-F GAMING
    • Chipset: AMD X570
    • RAM: ‎DIMM
    • Memory Speed: 4400 MHz
    • CPU Socket: Socket AM4
    • Operating System: Windows® 10 64-bit
    • Form Factor: ATX Form Factor 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
    • Compatible Processors: AMD 3rd Generation Ryzen
    • CPU: AMD AM4 Socket 3rd and 2nd AMD Ryzen™/2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors
    • Memory:
    • 3rd Gen AMD Ryzen™ Processors
    • 4 x DIMM, Max. 128GB, DDR4 4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3600(O.C.)/3400(O.C.)/3200(O.C.)/3000(O.C.)/2800(O.C.)/2666/2400/2133 MHz ECC and non-ECC, Un-buffered Memory
    • 2nd Gen AMD Ryzen™ Processors
    • 4 x DIMM, Max. 128GB, DDR4 3600(O.C.)/3400(O.C.)/3200(O.C.)/3000(O.C.)/2800(O.C.)/2666/2400/2133 MHz ECC and non-ECC, Un-buffered Memory
    • 2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors
    • 4 x DIMM, Max. 128GB, DDR4 3200(O.C.)/3000(O.C.)/2800(O.C.)/2666/2400/2133 MHz ECC and non-ECC, Un-buffered Memory
    • Dual Channel Memory Architecture
    • Graphic:
    • Integrated Graphics in the 2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors
    • Multi-VGA output support : HDMI/DisplayPort ports
    • - Supports HDMI 2.0b with maximum resolution of 4096 x 2160 @ 60 Hz
    • - Supports DisplayPort 1.2 with max. resolution 4096 x 2160 @ 60 Hz
    • Multi-GPU Support
    • 3rd and 2nd Gen AMD Ryzen™ Processors
    • Supports NVIDIA® 2-Way SLI® Technology
    • Supports AMD 3-Way CrossFireX™ Technology
    • 2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors
    • Supports AMD 2-Way CrossFireX™ Technology
    • Expansion Slots
    • 3rd Gen AMD Ryzen™ Processors
    • 2 x PCIe 4.0 x16 (x16 or dual x8)
    • 2nd Gen AMD Ryzen™ Processors
    • 2 x PCIe 3.0 x16 (x16 or dual x8)
    • 2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors
    • 1 x PCIe 3.0 x16 (x8 mode)
    • AMD X570 chipset
    • 1 x PCIe 4.0 x16 (max at x4 mode)
    • 2 x PCIe 4.0 x1
    • Storage
    • 3rd Gen AMD Ryzen™ Processors :
    • 1 x M.2 Socket 3, with M Key, Type 2242/2260/2280/22110(PCIE 4.0 x4 and SATA modes) storage devices support
    • 2nd Gen AMD Ryzen™/2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors :
    • 1 x M.2 Socket 3, with M Key, Type 2242/2260/2280/22110(PCIE 3.0 x4 and SATA modes) storage devices support
    • AMD X570 chipset :
    • 1 x M.2 x4 Socket 3, with M Key, Type 2242/2260/2280/22110(PCIE 4.0 x4 and SATA modes) storage devices support
    • 8 x SATA 6Gb/s port(s),
    • Support Raid 0, 1, 10
    • LAN:
    • Intel® I211-AT, 1 x Gigabit LAN Controller(s)
    • Anti-surge LANGuard
    • ROG GameFirst Technology
    • Audio:
    • SupremeFX 8-Channel High Definition Audio CODEC S1220A
    • - Dual OP Amplifiers
    • - Impedance sense for front and rear headphone outputs
    • - Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking
    • - High quality 120 dB SNR stereo playback output and 113 dB SNR recording input
    • - SupremeFX Shielding Technology
    • - Supports up to 32-Bit/192kHz playback
    • Audio Feature :
    • - Optical S/PDIF out port(s) at back panel
    • - Sonic Radar III
    • - Sonic Studio III + Sonic Studio Link
    • USB Ports:
    • 3rd and 2nd Gen AMD Ryzen™/2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors :
    • 4 x USB 3.2 Gen 1 port(s) (4 at back panel, )
    • AMD X570 chipset :
    • 1 x USB 3.2 Gen 2 front panel connector port(s)
    • AMD X570 chipset :
    • 4 x USB 3.2 Gen 2 port(s) (4 at back panel, , 3 x Type-A+1 x Type-C)
    • AMD X570 chipset :
    • 2 x USB 3.2 Gen 1 port(s) (2 at mid-board)
    • AMD X570 chipset :
    • 4 x USB 2.0 port(s) (4 at mid-board)
    • Features:
    • AMD X570 ATX gaming motherboard with PCIe 4.0, Intel Gigabit Ethernet, 14 power stages, dual M.2 with heatsinks, SATA 6Gb/s, USB 3.2 Gen 2 and Aura Sync RGB lighting
    • AMD AM4 socket: Ready for AMD Ryzen™ 5000 Series/ 4000 G-Series/ 3000 Series/ 3000 G-Series/ 2000 Series/ 2000 G-Series desktop processors; also supports up to two M.2 drives and features USB 3.2 Gen 2 and AMD StoreMI to maximize connectivity and speed
    • Aura Sync RGB: ASUS-exclusive Aura Sync RGB lighting, including RGB headers and addressable Gen 2 GRB headers
    • Optimal Power Solution: 12+2 power stages with ProCool II power connector, alloy chokes and durable capacitors to support multi-core processors
    • Comprehensive cooling: Active chipset heatsink, MOS heatsink with 8mm heatpipe, dual on-board M.2 heatsinks and a water pump + header
    • Gaming connectivity: Supports PCIe 4.0, HDMI 2.0, DisplayPort 1.2 and features dual M.2 and USB 3.2 Type-A and Type-C connectors
    • Gaming networking: Intel Gigabit Ethernet, ASUS LANGuard and GameFirst
    • 5-Way Optimization: Automated system-wide tuning, providing overclocking and cooling profiles that are tailor made for your rig
    • Gaming audio: High fidelity audio with SupremeFX S1220A, DTS® Sound Unbound and Sonic Studio III to draw you deeper into the action
    • Easy DIY: ROG-patented pre-mounted I/O shield, ASUS SafeSlot, ASUS Node connector and BIOS FlashBack™ for a friendlier building experience
