    Asus Prime B550M-A Wifi II Socket Am4 Ddr4 Comprehensive Cooling, Aura Sync RGB Lighting, PCIe 4.0 Gaming Motherboard

    Product Specifications

    • Brand: Asus
    • Model: Prime B550M-A Wifi II
    • CPU: AMD Ryzen™ 5000 Series/ 5000 G-Series/ 4000 G-Series/ 3000 Series Desktop Processors
    • *Refer to www.asus.com for CPU support list.
    • Chipset: B550
    • Memory: 4 x DIMM, Max. 128GB, DDR4
    • 4866(OC)/4800(OC)/4600(OC)/4466(OC)/4400(OC)/4333(OC)/4266(OC)/4200(OC)/4133(OC)/4000(OC)/3866(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200/3000/2933/2800/2666/2400/2133, Un-buffered Memory*
    • Dual Channel Memory Architecture
    • Graphics
    • 1 x D-Sub
    • 1 x D-Sub port
    • 1 x DVI-D port
    • 1 x HDMI® port**
    • Expansion Slots
    • AMD Ryzen™ 5000 Series/ 3000 Series Desktop Processors: 1 x PCIe 4.0 x16 slot (supports x16 mode)
    • AMD Ryzen™ 5000 G-Series/ 4000 G-Series Desktop Processors : 1 x PCIe 3.0 x16 slot (supports x16 mode)
    • AMD B550 Chipset: 2 x PCIe 3.0 x1 slots
    • Storage
    • Supports 2 x M.2 slots and 4 x SATA 6Gb/s ports
    • AMD Ryzen™ 5000 Series/ 3000 Series Desktop Processors
    • 2_1 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 & SATA modes)
    • AMD Ryzen™ 4000 G-Series Desktop Processors
    • 2_1 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 3.0 x4 & SATA modes)
    • AMD B550 Chipset
    • 2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 & SATA modes)
    • 4 x SATA 6Gb/s ports
    • Support RAID 0, 1, 10
    • Ethernet:
    • 1 x Realtek 1Gb Ethernet
    • ASUS LANGuard
    • Wireless & Bluetooth:
    • 2x2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax) + BT5.2
    • Wi-Fi 6
    • 2x2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax)
    • Supports 2.4/5GHz frequency band
    • Bluetooth v5.2
    • USB:
    • 2 x USB 3.2 Gen 2 ports (2 x Type-A)
    • 4 x USB 3.2 Gen 1 ports (4 x Type-A)
    • 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
    • 2 x USB 2.0 headers support additional 4 USB 2.0 ports
    • Audio:
    • Realtek 7.1 Surround Sound High Definition Audio CODEC*
    • - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
    • - Supports up to 24-Bit/192 kHz playback
    • Audio Features
    • - Audio Shielding
    • - LED-illuminated audio trace path design
    • - Premium audio capacitors
    • - Dedicated audio PCB layers
    • Back Panel I/O Ports:
    • 2 x USB 3.2 Gen 2 ports (2 x Type-A)
    • 4 x USB 3.2 Gen 1 ports (4 x Type-A)
    • 1 x D-Sub port
    • 1 x DVI-D port
    • 1 x HDMI® port
    • 1 x Wi-Fi Module
    • 1 x Realtek 1Gb Ethernet port
    • 3 x Audio jacks
    • 1 x PS/2 Keyboard/Mouse combo port
    • BIOS: 256 Mb Flash ROM, UEFI AMI BIOS
    • Operating System: Windows® 11 64-bit, Windows® 10 64-bit
    • Form Factor: microATX
    • Dimension: 24.4cm x 24.4cm
    • Special Features
    • ASUS 5X PROTECTION III
    • - DIGI+ VRM
    • - LANGuard
    • - Overvoltage Protection
    • - SafeSlot Core
    • - Stainless-Steel Back I/O
    • ASUS Q-Design
    • - Q-DIMM
    • - Q-Slot
    • ASUS Thermal Solution
    • - VRM heatsink design
    • AURA Sync
    • - AURA RGB headers
    • - Addressable Gen 2 header
    • Features:
    • AMD AM4 Socket: Ready for Ryzen™ 5000 Series/ 5000 G-Series/ 4000 G-Series/ 3000 Series Desktop Processors
    • Comprehensive Cooling: VRM heatsink, PCH heatsink, hybrid fan headers, and Fan Xpert 2+ utility
    • Ultrafast Connectivity: Dual M.2, PCIe 4.0, Wi-Fi 6, 1 Gb Ethernet, USB 3.2 Gen 2 Type-A support
    • Aura Sync RGB Lighting: Onboard addressable Gen 2 header and RGB headers for RGB LED strips, easily synced with Aura Sync-capable hardware
