Asus Prime Z370-A II Motherboard Socket 1151 Ddr4

₱7,459.00

Delivery Options

Same Day Delivery- Available within Metro Manila and Rizal*(Selected Cities Only)

Free Standard Delivery- Est. Arrival: 2-3 days

Payment Options

Dragonpay

Cash on Delivery

Asus Prime Z370-A II Motherboard Socket 1151 Ddr4

Product Specifications

  • CPU
  • Intel® Socket 1151 9th / 8th Gen Intel® Core™, Pentium® Gold and Celeron® Processors
  • Supports Intel® 14 nm CPU
  • Supports Intel® Turbo Boost Technology 2.0
  • * The Intel® Turbo Boost Technology 2.0 support depends on the CPU types.
  • * Refer to www.asus.com for CPU support list
  • Chipset
  • Intel® Z370
  • Memory
  • 4 x DIMM, Max. 64GB, DDR4 4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3400(O.C.)/3333(O.C.)/3300(O.C.)/3200(O.C.)/3000(O.C.)/2800(O.C.)/2666(O.C.)/2400(O.C.)/2133 MHz Non-ECC, Un-buffered Memory
  • Dual Channel Memory Architecture
  • Supports Intel® Extreme Memory Profile (XMP)
  • * Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
  • * The maximum memory frequency supported varies by processor.
  • Graphic
  • Integrated Graphics Processor- Intel® HD Graphics support
  • Multi-VGA output support : HDMI/DVI-D/DisplayPort ports
  • - Supports HDMI with max. resolution 4096 x 2160 @ 30 Hz
  • - Supports DVI-D with max. resolution 1920 x 1200 @ 60 Hz
  • - Supports DisplayPort with max. resolution 4096 x 2304 @ 60 Hz
  • Maximum shared memory of 1024 MB (for iGPU exclusively)
  • Supports Intel® InTru™ 3D, Quick Sync Video, Clear Video HD Technology, Insider™
  • Supports up to 3 displays simultaneously
  • DP 1.2 Multi-Stream Transport compliant, supports DP 1.2 monitor daisy chain up to 3 displays
  • Multi-GPU Support
  • Supports NVIDIA® 2-Way SLI™ Technology
  • Supports AMD 3-Way CrossFireX™ Technology
  • Expansion Slots
  • 2 x PCIe 3.0/2.0 x16 (x16, x8/x8, x8/x4+x4*, x8+x4+x4/x0**) *
  • 1 x PCIe 3.0/2.0 x16 (max at x4 mode)
  • 4 x PCIe 3.0/2.0 x1
  • * For 2 SSD on CPU support, install a Hyper M.2 X16 card (sold separately) into the PCIeX16_2 slot, enable this card under BIOS settings.
  • ** For 3 SSD on CPU support, install a Hyper M.2 X16 card (sold separately) into the PCIeX16_1 slot, enable this card under BIOS settings.
  • Storage
  • 1 x M.2 Socket 3, , with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode)*1
  • 1 x M.2 Socket 3, , with M Key, type 2242/2260/2280 storage devices support (PCIE mode only)*2
  • 6 x SATA 6Gb/s port(s), gray
  • Support Raid 0, 1, 5, 10
  • Intel® Rapid Storage Technology supports
  • Supports Intel® Smart Response Technology
  • Intel® Optane™ Memory Ready
  • LAN
  • Intel® I219V, 1 x Gigabit LAN Controller(s)
  • ASUS Turbo LAN Utility
  • ASUS LAN Guard
  • Audio
  • Realtek® S1220A 8-Channel High Definition Audio CODEC featuring Crystal Sound 3
  • - Impedance sense for front and rear headphone outputs
  • - Internal audio Amplifier to enhance the highest quality sound for headphone and speakers
  • - Supports : Jack-detection, Multi-streaming, Front Panel MIC Jack-retasking
  • - High quality 120 dB SNR stereo playback output and 113 dB SNR recording input (Line-in)
  • - Front panel audio connector (AAFP)
  • - Supports up to 32-Bit/192kHz playback *3
  • Audio Feature :
  • - DTS Headphone:X
  • - Audio Shielding: Ensures precision analog/digital separation and greatly reduced multi-lateral interference
  • - Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals
  • - Premium Japanese-made audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity
  • - Unique de-pop circuit: Reduces start-up popping noise to audio outputs
  • - Power pre-regulator: Reduces power input noise to ensure consistent performance
  • Separate layer for left and right track, ensuring both sound deliver equal quality
  • USB Ports
  • ASMedia® USB 3.1 Gen 2 controller :
  • 1 x USB 3.1 Gen 2 port(s) (1 at back panel, teal blue, Type-A, Support 3A power output)
ASMedia® USB 3.1 Gen 2 controller :
1 x USB 3.1 Gen 2 port(s) (1 at back panel, , USB Type-CTM, Support 3A power output)
Intel® Z370 Chipset :
6 x USB 3.1 Gen 1 port(s) (2 at back panel, , 4 at mid-board)
Intel® Z370 Chipset :
6 x USB 2.0 port(s) (2 at back panel, , 4 at mid-board)
