Asus Prime B550M-A Socket Am4 Ddr4 Motherboard
Review: 5 - "A masterpiece of literature" by , written on May 4, 20020
Great
ASUS

Asus Prime B550M-A Socket Am4 Ddr4 Motherboard

Available:In Stock
    ₱5,495.00
    Build Your PC With
    Delivery Options
    • Nationwide Delivery
    • Easy2get Delivery

      - As fast as 2 hours

    • Express Delivery

      - Delivery within 4 hours

    • Same Day Delivery

      - Order between 12:00AM to 12:00NN

    • Standard Delivery
    Payment Options
    • cash-on-delivery
    • 7eleven
    • gcredit
    • GCash
    • BillEase
    • GrabPay
    • Paymaya
    • Visa
    • Mastercard
    Warranty

    1 Year Warranty

    EasyFix Warranty

    Asus Prime B550M-A Socket Am4 Ddr4 Motherboard

    Product Description

    The ASUS Prime B550M-A AM4 motherboard blends reliability and performance, supporting AMD Ryzen processors and DDR4 memory. Featuring PCIe 4.0, M.2 slots, USB 3.2, and 5X Protection III for durability, it’s perfect for stable builds with enhanced connectivity and seamless multitasking capabilities.

    Product Specifications

    Model PRIME B550M-A
    CPU AMD AM4 Socket for AMD Ryzen 5000 Series/ 5000 G-Series/ 4000 G-Series/ 3000 Series Desktop Processors *
    Chipset AMD B550
    Memory 4 x DIMM, Max. 128GB, DDR4 4866(O.C)/4800(O.C.)/4600(O.C)/4466(O.C.)/4400(O.C)/4333(O.C.)/4266(O.C.)/4200(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3400(O.C.)/3333(O.C.)/3200/3000/2933/2800/2666/2400/2133 MHz Un-buffered Memory *
    Dual Channel Memory Architecture
    ECC Memory (ECC mode) support varies by CPU.
    * Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists), and memory frequency support depends on the CPU types.
    Graphic 1  x D-Sub
    1  x DVI-D
    1  x HDMI 2.1(4K@60HZ)
    *Graphics specifications may vary between CPU types.
    Expansion Slots AMD Ryzen™ 5000 Series/ 3000 Series Desktop Processors
    1 x PCIe 4.0 x16 (x16 mode)
    AMD Ryzen™ 5000 G-Series/ 4000 G-Series Desktop Processors
    1 x PCIe 3.0 x16 (x16 mode)
    AMD B550 Chipset
    2 x PCIe 3.0 x1
    LAN Realtek RTL8111H 1Gb Ethernet
    Audio Realtek ALC887/897 7.1 Surround Sound High Definition Audio CODEC
    - Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking, up to 24-Bit/192kHz playback
    Audio Feature :
    - LED-illuminated design
    - Audio Shielding
    - Dedicated audio PCB layers
    - Premium audio capacitors
    * Choose the chassis with HD audio module in front panel to support 8-channel audio output.
    USB Ports Rear USB Port ( Total 6  )
    2 x USB 3.2 Gen 2 port(s)(2 x Type-A)
    4 x USB 3.2 Gen 1 port(s)(4 x Type-A)
    Front USB Port ( Total 6  )
    2 x USB 3.2 Gen 1 port(s)(2 x Type-A)
    4 x USB 2.0 port(s)(4 x Type-A)
    Software Features ASUS Exclusive Software
    Armoury Crate
    - Aura Creator
    - Aura Sync
    AI Suite 3
    - Performance And Power Saving Utility
    TurboV EVO
    EPU
    Digi+ VRM
    Fan Xpert 2+
    - EZ update
    ASUS CPU-Z
    AI Charger
    DAEMON Tools
    Norton Anti-virus software (Free Trial for 60 days)
    WinRAR
    UEFI BIOS
    ASUS EZ DIY
    - ASUS CrashFree BIOS 3
    - ASUS EZ Flash 3
    - ASUS UEFI BIOS EZ Mode
    ASUS Special Features ASUS 5X PROTECTION III
    - ASUS DIGI+ VRM
    - ASUS LANGuard
    - ASUS Overvoltage Protection
    - ASUS SafeSlot Core
    - ASUS Stainless-Steel Back I/O
    ASUS Q-Design
    - ASUS Q-DIMM
    - ASUS Q-Slot
    ASUS Thermal Solution
    - Aluminum heatsink design
    AURA Sync
    - Standard RGB headers
    - Addressable Gen 2 RGB header
    ASUS Lighting Control
    Back I/O Ports 1 x PS/2 keyboard/mouse combo port(s)
    1 x DVI-D
    1 x D-Sub
    1 x HDMI
    1 x LAN (RJ45) port(s)
    2 x USB 3.2 Gen 2 (teal blue) (2 x Type-A)
    4 x USB 3.2 Gen 1 (blue) Type-A
    3 x Audio jack(s)
    Internal I/O Ports 1 x CPU Fan connector(s)
    1 x CPU OPT Fan connector(s)
    2 x Chassis Fan connector(s)
    2 x Aura RGB Strip Headers
    1 x Addressable Gen 2 header(s)
    1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s)
    2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
    1 x M.2 Socket 3 with M Key, type 2242/2260/2280/22110 storage devices support (SATA mode & X4 PCIE mode)
    1 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices support (SATA mode & X4 PCIE mode)
    1 x SPI TPM header
    4 x SATA 6Gb/s connector(s)
    1 x S/PDIF out header(s)
    1 x 24-pin EATX Power connector(s)
    1 x 8-pin EATX 12V Power connectors
    1 x Front panel audio connector(s) (AAFP)
    1 x Clear CMOS jumper(s)
    1 x System panel connector
    1 x COM port header
    1 x Speaker connector
    Accessories I/O Shield
    2 x SATA 6Gb/s cable(s)
    1 x Supporting DVD
    User manual
    1 x M.2 SSD screw package(s)
    BIOS 256 Mb Flash ROM, UEFI AMI BIOS
    Manageability WOL by PXE
    Operating System Windows® 10 64-bit
    Form Factor mATX Form Factor
      9.6  inch x 9.6  inch ( 24.4  cm x 24.4  cm )
