Gigabyte GA-A520m-ds3h Socket Am4 Ddr4 Motherboard
Review: 5 - "A masterpiece of literature" by , written on May 4, 20020
Great
EASYFIX
SAVE ₱150.00
Gigabyte GA-A520m-ds3h-b
Gigabyte GA-A520m-ds3h
Gigabyte GA-A520m-ds3h-a
Gigabyte GA-A520m-ds3h-c
Gigabyte GA-A520m-ds3h-d
Gigabyte GA-A520m-ds3h Socket Am4 Ddr4 Motherboard
Gigabyte GA-A520m-ds3h-b
Gigabyte GA-A520m-ds3h
Gigabyte GA-A520m-ds3h-a
Gigabyte GA-A520m-ds3h-c
Gigabyte GA-A520m-ds3h-d
Gigabyte GA-A520m-ds3h Socket Am4 Ddr4 Motherboard
GIGABYTE

Gigabyte GA-A520m-ds3h Socket Am4 Ddr4 Motherboard

Available:Out of Stock
    ₱4,300.00 ₱4,450.00
    Delivery Options
    • Nationwide Delivery
    • Easy2get Delivery

      - As fast as 2 hours

    • Express Delivery

      - Delivery within 4 hours

    • Same Day Delivery

      - Order between 12:00AM to 12:00NN

    • Standard Delivery
    Payment Options
    • cash-on-delivery
    • 7eleven
    • gcredit
    • GCash
    • BillEase
    • GrabPay
    • Paymaya
    • Visa
    • Mastercard
    Warranty

    1 Year Warranty

    EasyFix Warranty

    Gigabyte GA-A520m-ds3h Socket Am4 Ddr4 Motherboard

    • Brand
      Gigabyte
    • Model
      GA-A520m-ds3h
    • CPU Max Support
      AMD Socket AM4, support for: 3rd Generation AMD Ryzen™ processors/ 3rd Generation AMD Ryzen™ with Radeon™ Graphics processors
    • Socket
      AM4
    • Chipset
      AMD A520
    • Maximum Memory
      16 GB
    • Memory Channel
      Dual Channel
    • Sata III
      4
    • PCIE X16
      1
    • Form Factor
      Micro ATX Form Factor; 24.4cm x 24.4cm
    • Display Connectors
      1 x DVI-D port, 1 x DisplayPort, 1 x HDMI port
    • USB Ports
      4 x USB 3.2 Gen 1 ports on the back panel, 2 x USB 3.2 Gen 1 ports available through the internal USB header, 4 x USB 2.0/1.1 ports (2 ports on the back panel, 2 ports available through the internal USB header)
    • Dimension
      24.4cm x 24.4cm
    lorikeet

    Gigabyte GA-A520m-ds3h Socket Am4, Dual Channel, 3rd Gen Ryzen Support, Support for up to 3 displays Ddr4 Motherboard

    Product Description

    The Gigabyte GA-A520M-DS3H AM4 motherboard delivers reliable performance. With DDR4 support, it ensures seamless multitasking and efficient data handling. Upgrade your system with this budget-friendly motherboard for a reliable and responsive computing experience.

    Product Specifications

    • Brand: Gigabyte
    • Model: GA-A520m-ds3h
    • CPU: AMD Socket AM4, support for: 3rd Generation AMD Ryzen™ processors/ 3rd Generation AMD Ryzen™ with Radeon™ Graphics processors
    • (Please refer "CPU Support List" for more information.)
    • Chipset: AMD A520
    • Memory: 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory
    • 3rd Gen AMD Ryzen™ Processors:
    • Support for DDR4 4400(O.C.) / 4000(O.C.) / 3600(O.C.) / 3333(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz memory modules
    • 3rd Gen AMD Ryzen™ with Radeon™ Graphics processors:
    • Support for DDR4 4733(O.C.) / 4600(O.C.) / 4400(O.C.) / 4000(O.C.) / 3600(O.C.) / 3333(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz memory modules
    • Dual channel memory architecture
    • Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules
    • Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
    • Support for Extreme Memory Profile (XMP) memory modules
    • (Please refer "Memory Support List" for more information.)
    • Onboard Graphics: Integrated in the 3rd Generation AMD Ryzen™ with Radeon™ Graphics processors:
    • 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz
    • * The DVI-D port does not support D-Sub connection by adapter.
    • 1 x DisplayPort, supporting a maximum resolution of 5120x2880@60 Hz
    • * Support for DisplayPort 1.4 version, HDCP 2.3, and HDR.
    • 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
    • * Support for HDMI 2.1 version, HDCP 2.3, and HDR.
    • Support for up to 3 displays at the same time
    • Maximum shared memory of 16 GB
    • Audio: Realtek® ALC887 codec
    • High Definition Audio
    • 2/4/5.1/7.1-channel
    • * To configure 7.1-channel audio, you need to open the audio software and select Device advanced settings > Playback Device to change the default setting first. Please visit GIGABYTE's website for details on configuring the audio software.
    • LAN: Realtek® GbE LAN chip (1000 Mbit/100 Mbit)
    • Expansion Slots
    • CPU:
    • 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x16
    • Chipset:
    • 2 x PCI Express x1 slots, supporting PCIe 3.0 (PCIEX1_1, PCIEX1_2)
    • Storage Interface
    • CPU:
    • 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe 3.0 x4/x2 SSD support)
    • Chipset:
    • 4 x SATA 6Gb/s connectors
    • Support for RAID 0, RAID 1, and RAID 10
    • USB
    • CPU:
    • 4 x USB 3.2 Gen 1 ports on the back panel
    • Chipset:
    • 2 x USB 3.2 Gen 1 ports available through the internal USB header
    • 4 x USB 2.0/1.1 ports (2 ports on the back panel, 2 ports available through the internal USB header)
    • BIOS: 1 x 128 Mbit flash
    • Use of licensed AMI UEFI BIOS
    • PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
    • Operating System: Support for Windows 10 64-bit
    • Form Factor: Micro ATX Form Factor; 24.4cm x 24.4cm
