AMD Ryzen 5 3600 Processor + Gigabyte B450M-DS3H Motherboard Bundles

AMD Ryzen 5 3600 Processor + Gigabyte B450M-DS3H Motherboard Bundles

Product Specifications Processor

• Brand: AMD
• Model: Ryzen 5 3600
• # of CPU Cores: 6
• # of Threads: 12
• Base Clock: 3.6GHz
• Max Boost Clock: Up to 4.2GHz
• Total L1 Cache: 384KB
• Total L2 Cache: 3MB
• Total L3 Cache: 32MB
• Unlocked: Yes
• CMOS: TSMC 7nm FinFET
• Package: AM4
• PCI Express® Version: PCIe 4.0 x16
• Default TDP / TDP: 65W
• Max Temps: 95°C
• *OS Support: Windows 10 - 64-Bit Edition
• RHEL x86 64-Bit
• Ubuntu x86 64-Bit
• *Operating System (OS) support will vary by manufacturer
• System Memory Specification: Up to 3200MHz
• System Memory Type: DDR4
• Memory Channels: 2
• Overview:
• The world's most advanced processor in the desktop PC gaming segment
• Can deliver ultra-fast 100+ FPS performance in the world's most popular games
• 6 cores and 12 processing threads bundled with the quiet AMD wraith stealth cooler max temps 95°C
• 4 2 GHz max boost unlocked for overclocking 35 MB of game cache DDR4 3200 support
• For the advanced socket AM4 platform can support PCIe 4 0 on x570 motherboards

Product Specifications Motherboard

• Brand: Gigabyte
• Model: GA-B450M DS3H
• CPU: AM4 Socket: Supports AMD Ryzen™ 5000 series / Ryzen™ 5000 G-Series/ 3rd Gen Ryzen™/ 2nd Gen Ryzen™/ 1st Gen Ryzen™/ 2nd Gen Ryzen™ with Radeon™ Vega Graphics/ 1st Gen Ryzen™ with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega Graphics Processors.
• Chipset: AMD B450
• Memory:
• 4 x DDR4 DIMM sockets supporting up to 128 GB of system memory
• Dual channel memory architecture
• Support for DDR4 3600(O.C.)/3466(O.C.)/3200(O.C.)/2933/2667/2400/2133 MHz memory modules
• Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
• Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
• Support for Extreme Memory Profile (XMP) memory modules
• Onboard Graphics
• Integrated Graphics Processor:
• 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz
• The DVI-D port does not support D-Sub connection by adapter.
• 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz(Note)
• Support for HDMI 2.0 version and HDCP 2.2.(Note)
• Maximum shared memory of 16 GB
• Audio
• Realtek® Audio CODEC
• High Definition Audio
• 2/4/5.1/7.1-channel
• To configure 7.1-channel audio, you have to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver.
• Support for S/PDIF Out
• LAN: Realtek® GbE LAN chip (10/100/1000 Mbit)
• Expansion Slots
• 1 x PCI Express x16 slot, running at x16 (PCIEX16)(Note)
• For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
• (The PCIEX16 slot conforms to PCI Express 3.0 standard.)
• 1 x PCI Express x16 slot, running at x4 (PCIEX4)
• 1 x PCI Express x1 slot
• (The PCIEX4 and PCI Express x1 slots conform to PCI Express 2.0 standard.)
• Multi-Graphics Technology: Support for AMD Quad-GPU CrossFire™ and 2-Way AMD CrossFire™ technologies
• Storage Interface
• 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe x4/x2* SSD support)
• Actual support may vary by CPU.
• Supports only M.2 SATA SSDs when using an AMD Athlon™-series/ 7th Gen. A-series or Athlon™ X4 APU.
• 4 x SATA 6Gb/s connectors
• Support for RAID 0, RAID 1, and RAID 10
• Refer to "1-7 Internal Connectors," for the installation notices for the M.2 and SATA connectors.
• USB
• Chipset:
• 2 x USB 3.1 Gen 1 ports available through the internal USB header
• 8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers)
• CPU: 4 x USB 3.1 Gen 1 ports on the back panel
• Internal I/O Connectors
• 1 x 24-pin ATX main power connector
• 1 x 8-pin ATX 12V power connector
• 1 x CPU fan header
• 1 x system fan header
• 1 x M.2 Socket 3 connector
• 4 x SATA 6Gb/s connectors
• 1 x front panel header
• 1 x front panel audio header
• 1 x S/PDIF Out header
• 1 x CPU cooler LED strip/RGB LED strip header
• 1 x USB 3.1 Gen 1 header
• 2 x USB 2.0/1.1 headers
• 1 x Trusted Platform Module (TPM) header (2x10 pin, for the GC-TPM2.0 module only)
• 1 x serial port header
• 1 x Clear CMOS jumper
• Back Panel Connectors
• 1 x PS/2 keyboard/mouse port
• 1 x DVI-D port
• 1 x HDMI port
• 4 x USB 3.1 Gen 1 ports
• 4 x USB 2.0/1.1 ports
• 1 x RJ-45 port
• 3 x audio jacks
• I/O Controller: iTE® I/O Controller Chip
• H/W Monitoring
• Voltage detection
• Temperature detection
• Fan speed detection
• Overheating warning
• Fan fail warning
• Fan speed control
• Whether the fan speed control function is supported will depend on the cooler you install.
• BIOS
• 1 x 128 Mbit flash
• Use of licensed AMI UEFI BIOS
• PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
• Unique Features
• Support for APP Center
• Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
• 3D OSD
• AutoGreen
• Cloud Station
• EasyTune
• Fast Boot
• Game Boost
• ON/OFF Charge
• RGB Fusion
• Smart Backup
• Smart Keyboard
• Smart TimeLock
• Smart HUD
• Smart Survey
• System Information Viewer
• USB Blocker
• V-Tuner
• Support for Q-Flash
• Support for Xpress Install
• Operating System
• Support for Windows 10 64-bit
• Support for Windows 7 64-bit
• To support Windows 7 64-bit, you must install an AMD Pinnacle Ridge & Summit Ridge CPU.
• Please download the "Windows USB Installation Tool" from GIGABYTE's website and install it before installing Windows 7.
• Form Factor
• Micro ATX Form Factor; 24.4cm x 21.5cm
• Features
• Supports AMD Ryzen™ 5000 series / Ryzen™ 5000 G-Series/ 3rd Gen Ryzen™/ 2nd Gen Ryzen™/ 1st Gen Ryzen™/ 2nd Gen Ryzen™ with Radeon™ Vega Graphics/ 1st Gen Ryzen™ with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega Graphics Processors
• Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs
• HDMI, DVI-D Ports for Multiple Display
• Ultra-Fast PCIe Gen3 x4 M.2 with PCIe NVMe & SATA mode support
• High Quality Audio Capacitors and Audio Noise Guard with LED Trace Path Lighting
• RGB Fusion supports RGB LED Strips in 7-Colors
• Realtek® Gigabit LAN with cFosSpeed Internet Accelerator Software
• Smart Fan 5 Features 5 Temperature Sensors and 2 Hybrid Fan Headers with FAN STOP
• APP Center Including EasyTune™ and Cloud Station™ Utilities
• CEC 2019 Ready, Save Power with a Simple Click
